Well that’s a wonderful question all you have too do is hit a button on your phone.
What you have too do is go into Node RED UI and press the enter hold off you then have 10 seconds to enter or exit the room without setting it off.
HOW DO I TURN IT OFF WHEN I ENTER OR EXIT
The case is 3D printed and has two parts held together by 6 screws. 4 to hold the main board down and 2 on the sides of the second piece to connect the two parts.
.
What if i don’t want the motion detector on
All you have to do is go into Node Red UI and press the switch that says
SECURITY MONITOR
CASE
SUPPLIES
- Raspberry PI model B+
- OLED
- Reed Switch
- PIR ( motion sensor)
- Button
- Three way Switch
- A lot of wire
- LED
- Solder
- Soldering iron
Below are a list of supplies you will need to build this project. These supplies are fairly cheap and easy to come by.
The room security monitor is mounted above your door with a magnet stuck to the top of your door directly below the reed switch. The way it works is when someone opens the door the magnet makes the reed switch close which triggers the camera and OLED you then get sent three photos how ever many seconds apart you chose of whoever opened your door. The OLED also turns red whenever the reed switch is closed and stays red until you reset it.
The main board used for the Security Monitor is the Raspberry PI Model B+ and Node Red is used to write the code.
